lumbar external drainage sh025

Product Description

Product Description

'External CSF Drainage System' contains one bag, one 30cm lumbar catheter with 14G Touhey needle connector, suture collar & connecting tube.

The SURGIWEAR 'External CSF Drainage System' is designed to monitor or drain Cerebro Spinal Fluid to outside body into a closed system. Each system contains one ventricular catheter / lumbar catheter and one collection system which includes bag.

One Lumbar part (lumbar end) radio-opaque 30 cm long OD 1.5 mm ID 0.7 mm . Proximal end bears multiple holes. The tube is marked at 5 cm, 10 cm and 15 cm distance from proximal perforated tip. It can pass through 14 gauge Touhey needle. The catheter is supported by a teflon coated guide wire with flexible tip.

One CSF collection bag made up of one unitized PVC bag of 40 x 16 cm containing two separate measuring chambers of 900 ml & 50 ml attached with air vent, inlet unit, outlet point and a holding cord. Inlet unit is attached to a connecting tube haveing a stopper and luer lock connector. Drip chamber of inlet unit can be used to monitor fluid flow.A measuring scale is also attached to the PVC bag for regulating flow by way of lowering or raising the bag.

One Interconnecting tube 130 cm long provided with a flow regulator, stopper and a three way stop cock. Both ends have suitable luer lock connectors.

Supplied ready to use in peel open packs sterilized by EO
